Name: 24V / 48V Rack Mount Lifepo4 Battery Modular Design For Solar Energy Storage Systems
Brand: Heyi Energy Co,.ltd
SKU: 5KWH
Price: 600.00 USD
Availability: InStock

Home > products > Home Energy Storage System >

24V / 48V Rack Mount Lifepo4 Battery Modular Design For Solar Energy Storage Systems

Modular 48v rack mount lithium battery

Rack Mount Lifepo4 Battery Modular Design

24V Rack Mount Lifepo4 Battery

Place of Origin:

CHINA

Brand Name:

HEYI

Certification:

UN38.3 , MSDS , IS9001

Model Number:

5KWH

Request A Quote

24V / 48V Rack Mount Lifepo4 Battery Modular Design For Solar Energy Storage Systems

Product Details

Logo:

Can Be Customized

Battery Cell:

LifePO4 3.2V

Temperature Range:

Wide

Protocol:

RS485 And RS232

Protection:

Built-in BMS

Nominal Voltage:

24V 48V

Standard Charge Current:

Constant Current 1C

Capacity:

5.12 KWh

Design:

Rack Mounted

Cell Type:

Prismatic Cell

The Discharge Rate:

Keywords:

Battery Lithium Lifepo4

Chemistry:

LiFePO4

The Charging Ratio:

100Ah

Storage Type:

Normal

Installation:

Indoor Or Outdoor

Highlight:

Modular 48v rack mount lithium battery

Rack Mount Lifepo4 Battery Modular Design

24V Rack Mount Lifepo4 Battery

Payment & Shipping Terms

Minimum Order Quantity

Price

USD500~700

Packaging Details

wooden case

Delivery Time

10 working days

Payment Terms

T/T,Western Union,MoneyGram

Supply Ability

1 GWH

Safe 5KWH Lifepo4 Battery Wall Mounted Energy Storage Battery Space Saving

Get Best Price

24V / 48V Rack Mount Lifepo4 Battery Modular Design For Solar Energy Storage Systems

Get Best Price

High Capacity 20kwh Lithium Battery All In One Inverter Battery For Home Energy Storage System

Get Best Price

video

51.2V300ah 15kwh Lifepo4 Battery All In One Solar Battery Easy Installation

Get Best Price

+86 18674708020

info@heyienergy.com

Contact Now

Product Description

24V / 48V LiFePO4 Modular Battery for Solar Energy Storage Systems

Our 24V and 48V LiFePO₄ Modular Battery Series is a high-performance energy storage solution designed for residential, commercial, and telecom applications. Built with brand-new Grade A lithium iron phosphate cells and an advanced BMS, this battery offers outstanding safety, long lifespan, and simple installation.

Whether you’re upgrading an existing system or starting from scratch, this modular battery is engineered for reliable power in both off-grid and poor-grid environments.

24V / 48V Rack Mount Lifepo4 Battery Modular Design For Solar Energy Storage Systems 0

Specification :

Model	SM24-100	SM24-150	SM24-200	SM48-50	SM48-100	SM48-150
Energy	2560Wh	3840Wh	5120Wh	2400Wh	4800Wh	7200Wh
Nominal Voltage (V)	25.6V	25.6V	25.6V	48V	48V	48v
Rated Capacity (Ah)	100Ah	150Ah	200Ah	50Ah	100Ah	150Ah
Chemistry	Lithium Iron Phosphate (LiFePo4)
Design Life	More than 10 years
Cycle Life	More than 3500 cycles at 80% DOD.
Communication Protocol	CAN , RS485 , RS232
Display	LED Display Optional
Internal Impedance	50 mΩ
Max. Charging Current	50A	80A	100A	50A	100A	100A
Max. Continue Discharging Current	80A	100A	100A	70A	100A	100A
Battery Dimensions (MM)	438375133mm	442400177mm	442400177mm	438375133mm	442400177mm	442400177mm
Weight	Approx: 40kg	Approx: 58kg	Approx: 70kg	Approx: 40kg	Approx: 70kg	Approx: 80kg
Battery Protection	Over-charge &Over discharge protection , over current protection ,over temperature production , short-circuit products , cells balance
Outer Package Material	Black Power Coated steel case (battery rack or cabinet is optional)
Operating Temperature	Charging: 0 to +50℃ Discharging: -20 to +60℃ Storage: -20 to +60℃

24V / 48V Rack Mount Lifepo4 Battery Modular Design For Solar Energy Storage Systems 1

Features :

Safe and stable lithium iron phosphate (LiFePO₄) chemistry with built-in protection
High energy density in a compact footprint
Supports high charge and discharge currents for fast charging
Long lifespan with over 6000+ cycles at 80% depth of discharge (DOD)
Intelligent Battery Management System (BMS) for real-time protection against over-charge, over-discharge, and overheating
Flexible, modular design for wall-mounted or cabinet-mounted installation
Wide operating temperature range for stable performance in various environments

24V / 48V Rack Mount Lifepo4 Battery Modular Design For Solar Energy Storage Systems 2

Applications :

Home solar storage systems
Wind-solar hybrid systems
Telecom base stations
Emergency backup power
Stationary energy storage projects

24V / 48V Rack Mount Lifepo4 Battery Modular Design For Solar Energy Storage Systems 3
