24V200Ah Lifepo4 Home Battery Storage System Rack Mounted Lithium Battery 5.12kWh

24V200Ah Lifepo4 Home Battery Storage System Rack Mounted Lithium Battery 5.12kWh

24V200Ah Lifepo4 Home Battery

24V200Ah Rack Mounted Lithium Battery

5.12kWh Rack Mounted Lithium Battery

Place of Origin:

CHINA

Brand Name:

HEYI

Certification:

UN38.3 , MSDS , IS9001

Model Number:

24V200AH

Contact Us
Request A Quote
Product Details
Nominal Voltage:
24V
Protocol:
RS485 And RS232
Battery Cell:
LifePO4 3.2V
Capacity:
5.12 KWh
Protection:
Built-in BMS
Temperature Range:
Wide
Standard Charge Current:
Constant Current 1C
Logo:
Can Be Customized
Design:
Rack Mounted
Cell Type:
Prismatic Cell
The Discharge Rate:
1C
Keywords:
Battery Lithium Lifepo4
Chemistry:
LiFePO4
Installation:
Indoor Or Outdoor
Highlight:

24V200Ah Lifepo4 Home Battery

,

24V200Ah Rack Mounted Lithium Battery

,

5.12kWh Rack Mounted Lithium Battery

Payment & Shipping Terms
Minimum Order Quantity
1
Price
USD400~800
Packaging Details
wooden case
Delivery Time
10 working days
Payment Terms
T/T,Western Union,MoneyGram
Supply Ability
1 GWH
Product Description

Lifepo4 Batteries For Solar System 24V 200Ah Lithium Battery

Looking for a high-capacity 24V 200Ah LiFePO₄ rack-mounted battery at wholesale pricing? Our modular lithium battery is engineered for long-lasting performance, safety, and easy integration into various energy storage systems—ideal for solar ESS, telecom stations, off-grid setups, and backup power systems.

This advanced battery uses brand-new Grade A lithium iron phosphate (LiFePO₄) cells, offering superior thermal stability and an ultra-long cycle life. With its smart BMS (Battery Management System), it ensures real-time protection against over-voltage, under-voltage, current spikes, short circuits, and temperature extremes.

Designed for parallel expansion, the system is fully scalable, making it an excellent choice for residential, commercial, or industrial energy storage applications.



24V200Ah Lifepo4 Home Battery Storage System Rack Mounted Lithium Battery 5.12kWh 0

Specification :



Model SM24-100 SM24-150 SM24-200 SM48-50 SM48-100 SM48-150
Energy  2560Wh 3840Wh 5120Wh 2400Wh 4800Wh 7200Wh
Nominal Voltage (V) 25.6V 25.6V 25.6V 48V 48V 48v
Rated Capacity (Ah) 100Ah 150Ah 200Ah 50Ah 100Ah 150Ah
Chemistry Lithium Iron Phosphate (LiFePo4)
Design Life More than 10 years
Cycle Life More than 3500 cycles at 80% DOD.
Communication Protocol CAN , RS485 , RS232
Display LED Display Optional
Internal Impedance 50 mΩ
Max. Charging Current 50A  80A 100A 50A 100A  100A
Max. Continue Discharging Current 80A 100A 100A 70A 100A 100A
Battery Dimensions (MM) 438*375*133mm 442*400*177mm 442*400*177mm 438*375*133mm 442*400*177mm 442*400*177mm
Weight  Approx: 40kg Approx: 58kg Approx: 70kg Approx: 40kg Approx: 70kg Approx: 80kg
Battery Protection  Over-charge &Over discharge protection , over current protection ,over temperature production , short-circuit products , cells balance
Outer Package Material Black Power Coated steel case (battery rack or cabinet is optional)
Operating Temperature Charging: 0 to +50 Discharging: -20 to +60 Storage: -20 to +60













 24V200Ah Lifepo4 Home Battery Storage System Rack Mounted Lithium Battery 5.12kWh 1





  Features :



  • Safe and Stable LiFePO₄ Chemistry
    Built with high-quality lithium iron phosphate cells for exceptional thermal stability and safety.
  • Compact Design with High Energy Density
    Delivers more power in a smaller footprint, ideal for space-constrained installations.
  • High Charge and Discharge Capability
    Supports large current input and output for fast charging and stable operation under load.
  • Ultra-Long Lifespan
    Offers 6000+ cycles at 80% depth of discharge (DOD), ensuring more than 10 years of reliable service.
  • Advanced Battery Management System (BMS)
    Provides intelligent real-time protection against overcharge, over-discharge, short circuits, overheating, and other electrical faults.
  • Modular, Flexible Installation
    Suitable for wall-mounted or cabinet-mounted setups, supporting both small and large-scale system integration.
  • Wide Operating Temperature Range
    Performs reliably in diverse environments, from -20°C to 60°C.

 24V200Ah Lifepo4 Home Battery Storage System Rack Mounted Lithium Battery 5.12kWh 2









Applications :

  • Home solar storage systems

  • Wind-solar hybrid systems

  • Telecom base stations

  • Emergency backup power

  • Stationary energy storage projects

24V200Ah Lifepo4 Home Battery Storage System Rack Mounted Lithium Battery 5.12kWh 3
